Important excerpt from the ARP catalog regarding proper fastener installation: “The importance of tightening fasteners to their required preload cannot be emphasized enough. If a fastener is not preload cannot be emphasized enough. If a fastener is not tightened properly, the fastener will not apply the required preload on the application it is being used for and may become susceptible to failure. Conversely, if a fastener is over tightened and stretched too much, it becomes susceptible to failure by exceeding it’s maximum yield point.”
Underhead Length: 1.500 in. - Recommended Stretch (w/ ARP Lube): .0058-.0062 in. - Qty: 4
Manley Connecting Rod Bolt - Replacement Parts - Cap Screws 3/8" ARP 2000 - 1.500" UHL. For H-Beam Standard Weight, H-Lite Series and Pro Series I-Beam. Stretch .0058" to .0062" ARP2000 mat'l 55-65 w/oil 45-55 w/lube
- Premium ARP-manufactured rod bolts engineered for high clamp load and reliability
- Provides consistent preload when installed using recommended stretch method
- Precision thread rolling and heat treatment for maximum tensile strength
- Ideal for high-horsepower, high-RPM street and racing applications
|
| Air Freight Prohibited: false |
| Not Carb Approved: false |
| Ltl Freight Required: false |
| Prop 65: Unknown |
| Part Type: automotive |
| Epa: N/A |
| Carb Acknowledgement Required: false |
| Regular Stock: t |
| Units Per Sku: 1 |
